Exploded Views and Parts List
Samsung Electronics 5-120
■ Parts List
No. SA/SNADescription Specification
Q'TY
Code No.
MCU-6EAE3 MCU-4EAE3
1 DB61-02443A CASE-TOP SGCC-M,T1.0 1 1 SNA
2 DB72-00408M INSULATION-ACCUMULATOR FOAM-PE,T3.0,GRAY 1 1 SNA
3 DB63-01341A COVER-CTRL BOX SGCC-M,T0.8 1 1 SNA
4 DB64-01404A CONTROL-BOX SGCC-M,T0.1 1 1 SNA
5 DB61-02454A CASE-BACK-MID SGCC-M,T1.0 1 1 SNA
6 DB90-02159A ASS'Y CASE CABI RH ASS'Y 1 1 SNA
6-1 DB61-02444A CASE-RIGHT SGCC-M,T1.0 1 1 SNA
6-2 DB61-00712A HOLDER-SIDE CABI SGCC-M,T2.3 2 2 SNA
7 DB61-02445A CASE-RIGHT-COVER SGCC-M,T1.0 1 1 SNA
8 DB61-03094A CASE-FRONT MID SGCC-M,T 1.0 1 - SNA
DB61-03094B CASE-FRONT MID SGCC-M,T 1.0 - 1 SNA
9 DB61-02453A CASE-FRONT UP SGCC-M,T 1.0 1 - SNA
DB61-02453B CASE-FRONT UP SGCC-M,T 1.0 - 1 SNA
10 DB90-03010A ASS'Y CASE CABI LF ASS'Y 1 1 SNA
10-1 DB61-03096A CASE CABI LF SGCC-M,T 1.0 1 1 SNA
10-2 DB61-00712A HOLDER-SIDE CABI SGCC-M,T2.3 2 2 SNA
11 DB61-03095A CASE BASE SGCC-M,T 1.0 1 - SNA
DB61-03095B CASE BASE SGCC-M,T 1.0 - 1 SNA
12 DB67-00620A DRAIN BOX HIPS,T2.0,BLK 1 1 SNA
13 DB96-08861A ASS'Y LIQUID LINE ASS'Y 1 - SNA
DB96-08838A ASS'Y LIQUID LINE ASS'Y - 1 SNA
13-1 DB62-04065A VALVE EXPANSION BODY DPF(Q)1.65C-06-RK(E) 1 1 SA
13-2 DB62-04067A VALVE EXPANSION COIL QA(M)12-RL-05A-RK(E) 1 1 SA
13-3 DB62-03904B VALVE EXPANSION ZEDM-A0YGSH 1 1 SA
13-4 DB33-00061B VALVE SOLENOID BODY ASS'Y 1 1 SA
13-5 DB96-07630A ASS'Y SOLENOID VALVE ASS'Y 1 1 SA
14 DB96-13497A ASS'Y GAS LINE ASS'Y 1 - SNA
DB96-13496A ASS'Y GAS LINE ASS'Y - 1 SNA
14-1 DB62-05468A VALVE SOLENOID BODY FDF13A-013-RK 12 8 SNA
14-2 DB99-00556J ASS'Y VALVE SOLENOID ASS'Y 6 4 SA
14-3 DB99-00556H ASS'Y VALVE SOLENOID ASS'Y 6 4 SA
14-4 DB33-00034A SOLENOID VALVE BODY FDF2A 1 1 SA
14-5 DB95-00403F ASS'Y SOLENOID COIL ASS'Y 1 1 SA
