Product Specifications
2-26 Samsung Electronics
Indoor Unit(cont.)
QWall Mounted type(Monblanc)
Model
AVXWBH028E6
ND028BH666
AVXWBH036E6
ND036BH666
AVXWBH056E6
ND056BH666
AVXWBH071E6
ND071BH666
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 2.8 3.6 5.6 6.8
Btu/h 9,500 12,200 19,100 23,200
Heating*
3)
kW 3.2 4.0 6.3 7.0
Btu/h 10,900 13,600 21,400 23,800
Condensate (with High fan speed) Liters/h 1.44 1.91 2.87 3.51
Power
Input W 30
*5)
35
*5)
50
*5)
55
*5)
Running Current A 0.18
*5)
0.19
*5)
0.30
*5)
0.32
*5)
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 31
*5)
/ 20
*5)
35
*5)
/ 21
*5)
40
*5)
/ 30
*5)
41
*5)
/ 30
*5)
Fan
Type - Crossflow fan Crossflow fan Crossflow fan Crossflow fan
Motor
Model - SFN-230-16-4W SFN-230-16-4W Y5S413B219 Y5S413B219
Type - SSR SSR SSR SSR
Output W - - - -
Airflow Rate
Cooling (High) m
3
/min 9.0
*5)
10.0
*5)
12.0
*5)
13.0
Heating (High) m
3
/min 9.0
*5)
10.0
*5)
12.0
*5)
13.0
Refrigerant
Type - R410A R410A R410A R410A
Control Method - EEV (Optional) EEV (Optional) EEV (Optional) EEV (Optional)
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35 9.52
Gas (Flare) ø, mm 12.7 12.7 12.7 15.88
Drain ø, mm ID 18 hose ID 18 hose ID 18 hose ID 18 hose
Weight
Net Weight kg 10.2
*5)
10.2
*5)
13
*5)
13
*5)
Shipping Weight kg 11.5
*5)
11.5
*5)
16
*5)
16
*5)
Dimensions
Net Dimensions (W x H x D) mm 900x304x185 900x304x185 1,100x307x225 1,100x307x225
Shipping Dimensions (W x H x D) mm 963x349x247 963x349x247 1157x381x292 1157x381x292
Functions
Auto Restart - O O O O
Auto Swing - O O O O
Group/Individual Control - O O O O
External Contact Control - O O O O
Trouble Shooting by LED - O O O O
Standard
Accessories
Installation Manual - O O O O
Operation Manual - O O O O
Pattern Sheet for Installation - X X X X
Flexible Drain Hose - O O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Wireless Remote Controller ARH-1364 ARH-1364 ARH-1364 ARH-1364
Optional
Accessories
Wireless Remote Controller - MR-BH01 MR-BH01 MR-BH01 MR-BH01
Wired Remote
Controller
Simplified - MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Standard - MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Premium - MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14 MIM-B14
EEV Kits MXD, MEV Series MXD, MEV Series MXD, MEV Series MXD, MEV Series
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
