Product Specifications
Samsung Electronics 2-27
Indoor Unit(cont.)
QWall Mounted type(Neo Forte without EEV)
Model
AVXWNH022E6
ND022NH666
AVXWNH028E6
ND028NH666
AVXWNH036E6
ND036NH666
AVXWNH056E6
ND056NH666
AVXWNH0716
ND071NH666
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW
2.2 2.8 3.6 5.6 6.8
Btu/h
7,500 9,500 12,200 19,100 23,200
Heating*
3)
kW
2.5 3.2 4.0 6.3 7.0
Btu/h
8,500 10,900 13,600 21,400 23,800
Condensate (with High fan speed) Liters/h
1.12 1.44 1.91 2.87 3.51
Power
Input W
25
*5)
25
*5)
30
*5)
45
*5)
50
*5)
Running Current A
0.16
*5)
0.16
*5)
0.18
*5)
0.27
*5)
0.30
*5)
Sound Level Sound Pressure (High/Low)*
4)
dB(A)
31/21 31/21 35/21 40
*5)
/ 30
*5)
41
*5)
/ 30
*5)
Fan
Type -
Crossflow fan Crossflow fan Crossflow fan Crossflow fan Crossflow fan
Motor
Model -
-----
Type -
Resin/steel Resin/steel Resin/steel Resin/steel Resin/steel
Output W
-----
Airflow Rate
Cooling (High) m
3
/min
7.80
*5)
7.80
*5)
9.30
*5)
12.00
*5)
14.00
*5)
Heating (High) m
3
/min
8.20
*5)
8.20
*5)
9.50
*5)
13.00
*5)
15.00
*5)
Refrigerant
Type -
R410A R410A R410A R410A R410A
Control Method -
EEV (Optional) EEV (Optional) EEV (Optional) EEV (Optional) EEV (Optional)
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices -
Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 9.52
Gas (Flare) ø, mm
12.7 12.7 12.7 12.7 15.88
Drain ø, mm
ID 18 hose ID 18 hose ID 18 hose ID 18 hose ID 18 hose
Weight
Net Weight kg
7.5
*5)
7.8
*5)
7.8
*5)
13.0
*5)
13.0
*5)
Shipping Weight kg
11.5
*5)
11.5
*5)
11.5
*5)
15.0
*5)
15.0
*5)
Dimensions
Net Dimensions (W x H x D) mm
825x285x189 825x285x189 825x285x189 1,099x315x217 1,099x315x217
Shipping Dimensions (W x H x D) mm
900x349x252 900x349x252 900x349x252 1,137x377x299 1,137x377x299
Functions
Auto Restart -
OOOOO
Auto Swing -
OOOOO
Group/Individual Control -
OOOOO
External Contact Control -
OOOOO
Trouble Shooting by LED -
OOOOO
Standard
Accessories
Installation Manual -
OOOOO
Operation Manual -
OOOOO
Pattern Sheet for Installation -
XXXXX
Flexible Drain Hose -
OOOOO
Filter / Safety Grille -
Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Wireless Remote Controller
ARH-1364 ARH-1364 ARH-1364 ARH-1364 ARH-1364
Optional
Accessories
Wireless Remote Controller -
MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Wired Remote
Controller
Simplified -
MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00 MWR-SH00
Standard -
MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01 MWR-TH01
Premium -
MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module -
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
EEV Kits
MXD, MEV Series MXD, MEV Series MXD, MEV Series MXD, MEV Series MXD, MEV Series
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
