PCB Diagram and Parts List
6-3 Samsung Electronics
■ Panel (AVXCSH022/028/036E✳, ND022/028/0361H✳✳✳)
DC
connecting
connector
①
#1~5 : Control Display LED
#6 : Not used
#7 : Receive signals from wireless remote controller
#8 : GND
#9 : VCC (DC5V)
CN01 : Connect the Main PBA of the Indoor Unit
1
