Product Specifications
Samsung Electronics 2-31
2-2-2 Outdoor Unit
Type
Development Model Comparative Model
Model RD080HHXG
✳
RD100HHXG
✳
RD120HHXG
✳
RVXVHT080GE RVXVHT100GE RVXVHT120GE
Mode HP HP HP HP HP HP
Power Supply Ø,V,Hz 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50
Performance
Horse Power HP 8 10 12 8 10 12
Capacity
Cooling
kW 22.4 28.0 33.6 22.4 28 33.6
Btu/h 76,400 95,500 114,600 76,400 95,500 114,600
Heating
kW 25.2 31.5 37.8 25.2 31.5 37.8
Btu/h 86,000 107,500 129,000 86,000 107,500 129,000
Power
Running
Current
Cooling A 8.80 13.00 20.00 12.2 13.9 21.0
Heating A 11.40 12.70 18.40 12.0 13.0 19.2
Maximum A 18.40 21.50 28.40 - - -
Input
Cooling kW 5.20 7.04 9.20 5.76 7.78 10.4
Heating kW 5.46 6.89 8.50 5.51 7.16 9.4
Power breaker(MCCB/ELB/ELCB) A 30 30 40 25 30 40
COP
Cooling - 4.31 3.98 3.65 3.89 3.60 3.23
Heating - 4.62 4.57 4.45 4.57 4.40 4.02
Compressor
Model -
ZPJ61KCE-TFD
ZPI61KCE-TFD
ZPJ61KCE-TFD
ZPI61KCE-TFD
ZPJ83KCE-TFD
ZPI83KCE-TFD
ZPJ61KCE-TFD
ZPI61KCE-TFD
ZPJ61KCE-TFD
ZPI61KCE-TFD
ZPJ83KCE-TFD
ZPI83KCE-TFD
Type - DVI *1 + FVl *1 DVI *1 + FVl *1 DVI *1 + FVl *1 DVI *1 + FVl *1 DVI *1 + FVl *1 DVI *1 + FVl *1
Output kW 4.36 + 4.36 4.36 + 4.36 5.87 + 5.87 4.36 + 4.36 4.36 + 4.36 5.87 + 5.87
Lubricant
Type - 3MAF POE 3MAF POE 3MAF POE 3MAF POE 3MAF POE 3MAF POE
Charging cc 4,370 4,370 4,370 3,370 3,370 3,370
Refrigerant
Type - R410A R410A R410A R410A R410A R410A
Factory Charging kg 5.0 5.0 5.0 7.5 7.5 7.5
FAN
Type/Control - Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC
Motor Output W 630 630 630 630 630 630
Airflow rate m/min 173 173 210 170 170 180
Pipe
Piping
connections
Liquid Ø,mm 9.52 9.52 12.70 9.52 9.52 12.70
Gas Ø,mm 19.05 22.20 25.40 19.05 22.20 25.40
Oil(Flare) Ø,mm 6.35 6.35 6.35 6.35 6.35 6.35
Installation
Limitation
Max. Length m 200 200 200 200 200 200
Max. Height m 50(40) 50(40) 50(40) 50(40) 50(40) 50(40)
Cable
Main Power(Below/about 20m) mm 1.5 2.5 4.0 2.5 2.5 4.0
Communication mm VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P)
Set Size
Net weight kg 237 237 240 240 240 240
Shipping Weight kg 253 253 256 253 253 253
Net dimension(WxHxD) mm 880x1695x765 880x1695x765 880x1695x765 880x1703x765 880x1703x765 880x1703x765
Shipping dimension(WxHxD) mm 948x1857x832 948x1857x832 948x1857x832 948x1868x832 948x1868x832 948x1868x832
Operating
Temp. Range
Cooling
°C
-5 ~ 48 -5 ~ 48 -5 ~ 48 -5 ~ 43 -5 ~ 43 -5 ~ 43
Heating -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24
