Product Specifications
2-32 Samsung Electronics
Outdoor Unit(cont.)
Type
Development Model Comparative Model
Model RD140HHXG
✳
RD160HHXG
✳
RD180HHXG
✳
RD200HHXG
✳
RVXVHT140GE RVXVHT160GE
Mode HP HP HP HP HP HP
Power Supply Ø,V,Hz 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50 3/380~415/50
Performance
Horse Power HP 14 16 18 20 14 16
Capacity
Cooling
kW 39.2 44.8 50.4 56.0 39.2 44.8
Btu/h 133,800 152,900 171,900 191,000 133,800 152,900
Heating
kW 44.1 50 56.7 63.0 44.1 50.4
Btu/h 150,500 172,000 193,500 215,000 150,500 172,000
Power
Running
Current
Cooling A 20.90 22.00 31.30 32.80 24.20 28.60
Heating A 19.40 27.20 26.70 29.10 23.00 29.20
Maximum A 29.40 38.30 42.50 44.10 - -
Input
Cooling kW 10.10 12.00 15.70 17.00 11.00 14.80
Heating kW 9.65 11.30 12.90 14.50 10.40 15.00
Power Breaker(MCCB/ELB/ELCB) A 40 50 60 60 40 40
COP
Cooling - 3.88 3.73 3.21 3.29 3.56 3.03
Heating - 4.57 4.42 4.40 4.34 4.24 3.36
Compressor
Model
ZPJ83KCE-TFD
ZPI83KCE-TFD
ZPJ72KCE-TFD
ZPI72KCE-TFD
ZPJ83KCE-TFD
ZPI83KCE-TFD
ZPJ83KCE-TFD
ZPI83KCE-TFD
ZPJ72KCE-TFD
ZPI61KCE-TFD
ZPJ72KCE-TFD
ZPI72KCE-TFD
Type - DVI *1 + FVl *1 DVI *1 + FVl *2 DVI *1 + FVl *2 DVI *1 + FVl *2 DVI *1 + FVl *2 DVI *1 + FVl *2
Output kW 5.87 + 5.87 5.16 + 5.16 X 2 5.87 + 5.87 X 2 5.87 + 5.87 X 2 5.16 + 4.36 X 2 5.16 + 5.16 X 2
Lubricant
Type - 3MAF POE 3MAF POE 3MAF POE 3MAF POE 3MAF POE 3MAF POE
Charging cc 4,370 6,540 6,540 6,540 5055 5055
Refrigerant
Type - R410A R410A R410A R410A R410A R410A
Factory Charging kg 7.0 7.0 8.5 8.5 11.0 11.0
FAN
Type/Control - Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC Propeller + BLDC
Motor Output W 630 X 2 630 X 2 630 X 2 630 X 2 630 630
Airflow rate m/min 226 250 270 275 210 210
Pipe
Piping
connections
Liquid Ø,mm 12.70 12.70 15.88 15.88 12.70 12.7
Gas Ø,mm 25.40 28.58 28.58 28.58 25.40 28.58
Oil(Flare) Ø,mm 6.35 6.35 6.35 6.35 6.35 6.35
Installation
Limitation
Max. Length m 200 200 200 200 200 200
Max. Height m 50(40) 50(40) 50(40) 50(40) 50(40) 50(40)
Cable
Main Power(Below/about 20m) mm 4.0 6.0 6.0 10.0 4.0 6.0
Communication mm VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P) VCTF 0.75~1.5(2P)
Set Size
Net weight kg 280 329 340 349 320 320
Shipping Weight kg 301 350 361 370 337 337
Net dimension(WxHxD) mm 1295x1695x765 1295x1695x765 1295x1695x765 1295x1695x765 1200x1703x765 1200x1703x765
Shipping dimension(WxHxD) mm 1363x1857x832 1363x1857x832 1363x1857x832 1363x1857x832 1268x1868x832 1268x1868x832
Operating
Temp. Range
Cooling
°C
-5 ~ 48 -5 ~ 48 -5 ~ 48 -5 ~ 48 -5 ~ 43 -5 ~ 43
Heating -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24 -20 ~ 24
