Disassembly and Reassembly
Samsung Electronics 3-12
No Parts Procedure Remark
4 Drain Pump 1) Unscrew the 2 screws that fix the Cover
Drain Pump. (Use + Screw Driver)
2) Release the Band Ring to separate the
Drain Hose from the Drain Pump.
3) Separate the Drain Pump from the
Indoor Unit.
5 Drain Sub 1) Unscrew the fixing screw for Drain Sub.
(Use + Screw Driver)
2) Hold the hook on the Drain sub and
separate it.
$9;&6+B$BaLQGG
To Next Page
