Disassembly and Reassembly
3-13 Samsung Electronics
No Parts Procedure Remark
6 Heat Exchanger 1) Unscrew a fixing screw for Heat
Exchanger. (Use + Screw Driver)
2) Separate the Indoor Sensor from the
Heat Exchanger.
3) Separate the EEV connector from the
PCB.
4) Separate the Heat Exchanger from the
Indoor Unit.
5) Separate the Expansion coil from the
EEV Body. (For EEV service)
$9;&6+B$BaLQGG
To Next Page
