Disassembly and Reassembly
Samsung Electronics 3-16
No Parts Procedure Remark
2) Detach from Assy control in the capacitor
connection wire b/w the motor fan & housing
connector.
3) After disassembling 3 places indicating
screws, detach Fan Motor and Blower from
the set.
2 Control In 1) After disassembling 2 Indicating screw,
detach the Cover control.
(Use + Screw Driver.)
$9;&6+B$BaLQGG
To Next Page
