Disassembly and Reassembly
3-17 Samsung Electronics
No Parts Procedure Remark
2) Detach the motor fan & sensor connector from
the PCB .
3) Disassemble 2 indicating screws and detach
Control In from the set.
(Use + Screw Driver.)
3 Drain Pan Work is possible when Disassembling the
Ass'y Cabi Bottom Blower.
1) Disassemble 7 indicating screws and detach
Ass'y Cabi Bottom Drain.
(Use + Screw Driver.)
$9;&6+B$BaLQGG
To Next Page
