Disassembly and Reassembly
Samsung Electronics 3-38
Binding Wire Large Chassis (RD160/180/200HHXG✳)
QBending Wire 1
󱁿
󱂃
QBending Wire 2
Valve & Sensor
No Valve & Sensor
󱁿
EVI Bypass Valve
󱂀
Oil-gas Valve
󱂁
PWM Valve
󱂂
Vapor Injection Valve 1
󱂃
Vapor Injection Valve 2
󱂄
Vapor Injection Valve 3
󱂅
Liquid Bypass Valve
󱂆
High Pressure Switch
󱂇
High Pressure Sensor
󱂈
Low Pressure Switch
󱂉
Hot-gas Valve
󱂊
4way Valve
󱂋
Temperature Sensor Suction (Black Wire)
Insulation
No HP Insu Code Binding Wire
󱂓
16/18/20/22 DB62-03808A -
Valve & Sensor
No Valve & Sensor
󱁿
Main EEV
󱂀
EVI EEV
󱂁
Temperature Sensor EVI In (Black Wire)
󱂂
Temperature SensorLiquid Pipe (White Wire)
󱂃
Temperature Sensor EVI Out (White Wire)
Insulation
No HP Insu Code Binding Wire
󱂓
16/18/20/22 DB62-03808E -
󱂔
16 DB62-03808C -
16/18/20/22 DB62-03808D -
󱂕
16/18/20/22 DB62-03808D -
󱂈
󱂉
󱂊
󱂁
󱂁
󱂀
󱁿
󱁿
󱂆
󱂅
󱂇
󱂋
󱂂
󱂂
󱂃
󱂄
Bending Cable Tie
Bending
Cable Tie
󱂓
󱂓
󱂔
󱂕
󱂀
