Pipe size between branch joints : (B) Tempers of pipe
Select the pipe size according to the capacity sum of indoor
units which are connected below this pipe.
Pipe size between branch joints and indoor unit (C)
Select the pipe size according to the indoor unit’s capacity.
Branch joint : (D), (E), (F)
 Branch joint of outdoor unit’s multi connection (D)
 First branch joint (E)
Select branch joint according to the outdoor unit’s
capacity.
 Branch joint (F)
Select the pipe size according to the capacity sum of
indoor units which are connected below this pipe.
1) Y-joint
2) Header joint
Total Indoor
unit’s capacity
Pipe size (O.D)
Liquid Gas
mm inches mm inches
51MBH
Ø9.52 Ø3/8
Ø15.88 Ø5/4
51~79MBH Ø19.05 Ø3/4
79~96MBH Ø22.23 Ø7/8
96~138MBH
Ø12.70 Ø1/2
Ø28.58 Ø1-1/8138~160MBH
160~240MBH Ø15.88 Ø5/8
240~336MBH
Ø19.05 Ø3/4 Ø34.93 Ø1-3/8
336~468MBH
Indoor unit’s
capacity
Pipe size (O.D)
Liquid Gas
mm inches mm inches
6~20MBH Ø6.35 Ø1/4 Ø12.70 Ø1/2
24~48MBH Ø9.52 Ø3/8 Ø15.88 Ø5/8
Outdoor multi
connection
Model
Capacity of outdoor
unit
branch joint (D)
MXJ-T3819 12 ~ 30 Ton
Y-joint
(E)
Model Capacity of outdoor unit
MXJ-YA2512 6, 8,10 Ton
MXJ-YA2812
 12 Ton
MXJ-YA2815
 14,16,18,20 Ton
MXJ-YA3119
 22, 24, 26, 28 Ton
MXJ-YA3819
 30 Ton
Y-joint
(F)
Model Capacity of outdoor unit
MXJ-YA1509 51 MBH and below
MXJ-YA2512 Over 51 MBH ~ 138 MBH and below
MXJ-YA2812 Over 138 MBH ~ 160 MBH and below
MXJ-YA2815 Over 160 MBH ~ 240 MBH and below
MXJ-YA3119 Over 240 MBH ~ 336 MBH and below
MXJ-YA3819 Over 336 MBH ~ 468 MBH and below
Header
joint
(F)
Model
Total Indoor
unit’s capacity
The
connectable
quantity of
indoor units
MXJ-HA2512
160 MBH and
below
4
MXJ-HA3115
Over 160 MBH~
240 MBH
8
MXJ-HA3819 Over 240 MBH 8
Pipe size Thickness
Material
mm inches mm inches
Ø6.35 Ø1/4
0.7 0.027
C1220T-O (Annealed)
Ø9.52 Ø3/8
Ø12.70 Ø1/2 0.8 0.031
Ø15.88 Ø5/8 1.0 0.039
Ø19.05 Ø3/4
0.9 0.035
C1220T-1/2H
(Drawn temper)
Ø22.23 Ø7/8
Ø25.40 Ø1 1.0 0.039
Ø28.58 Ø1-1/8
1.1 0.043
Ø31.75 Ø1-1/4
Ø34.93 Ø1-3/8 1.2 0.047
Ø38.10 Ø1-1/2 1.35 0.053
Ø44.45 Ø1-3/4 1.6 0.062
Ø50.80 Ø2 2.0 0.079
• Make sure to use C1220T-1/2H pipe for
more than Ø19.05mm(3/4˝).
In case of using C1220T-O pipe for
Ø19.05mm(3/4˝) pipe may be broken,
which can result in an injury.
CAUTION
DVM PLUS3_IM_E_31180-4.indd 17 2009-12-21 ｿﾀﾈﾄ 1:11:29
