Connection Using an HDMI Cable

HDMI IN (DVI)

Connection Using an HDMI-DVI Cable

―

When you connect a PC to the product using an HDMI-DVI cable, set Edit Name to DVI PC to access

video and audio content stored on the PC.

HDMI IN (DVI)

RGB / DVI AUDIO IN
