18
Side Views of Your Device
1.
3.5mm Headset jack
: Allows you to plug in headphones.
2.
Microphone
: Used for noise cancellation and stereo
recording.
3.
Volume keys
: Used to adjust the ringer volume while in
standby mode or adjust the voice volume during a call.
When receiving an incoming call, briefly press down
either volume key to mute the ring tone. Adjusts text
size when reading a message.
4. Power/Lock key: Used to power your device on and
off. Also allows you to lock or unlock the touch screen.
For more information, refer to “Locking and Unlocking
the Screen” on page 13.
5.
Microphone
: Makes it possible for other callers to hear
you when you are speaking to them. It is also used for
the Speakerphone.
6. Power/Accessory Interface connector: Used to
connect a Travel Charger or other optional accessories
such as a USB/data cable or a hands-free headset for
convenient, hands-free conversations.
