Samsung SR8980 - Main Unit Parts Identification

assembling _17
02 ASSEMBLING
NAME OF EACH PART
Front
Bottom
Side
■
Main unit
Virtual Guard Sensor, Mike
Dustbin Eject Button
Camera
Obstacle Sensor
Dustbin Eject Button
Dust bin
Driving Wheel
Power Switch
Power Brush
Power Brush Cover
Battery Cover
Driving Wheel
Remote Control Sensor
Obstacle Sensor
Bumper Sensor
Remote Control Sensor
Rotating Side Brush
Cliff Sensor
Charge Pin
Roller
Cliff Sensor
Charge Pin
Cliff Sensor
Display panel
Monitoring Camera
Light
