Samsung U28D590D

53
Screen Adjustment
4
4 Screen Adjustment
4.3.3 Configuring Position
Select the position of the sub-screen from the available options.
1 When the Function Key Guide appears, select [ ] by moving the JOG button UP.
Next, press the JOG button.
2 Move to Screen controlling the JOG button UP/DOWN and press the JOG button.
3 Move to the PIP/PBP controlling the JOG button UP/DOWN and press the JOG button.
4 Move to the Position controlling the JOG button UP/DOWN and press the JOG button.
The following screen will appear.
 / / /
5 Move to the desired option controlling the JOG button UP/DOWN and press the JOG button.
6 The selected option will be applied.
 Not available when PBP is selected.
 The screen may flicker if the input signal is unstable.
PIP/PBP
Select the position of
the sub-screen from
the available options.
2Q
PIP/PBP Mode
Size
Position
Sound Source
Source
Image Size
Contrast
