Samsung U28D590D

55
Screen Adjustment
4
4 Screen Adjustment
4.3.5 Configuring Source
Select the source for each screen.
PIP
1 When the Function Key Guide appears, select [ ] by moving the JOG button UP.
Next, press the JOG button.
2 Move to Screen controlling the JOG button UP/DOWN and press the JOG button.
3 Move to the PIP/PBP controlling the JOG button UP/DOWN and press the JOG button.
4 In PIP mode (Size / / ), move the JOG button UP/DOWN to select Source and then
press the JOG button.
The following screen will appear.
 HDMI 1
 HDMI 2
 DisplayPort
5 Move to the desired option controlling the JOG button UP/DOWN and press the JOG button.
6 The selected option will be applied.
 The input source for the main screen changes.
 With the exception of the current input source, the other two input sources can be selected.
 The screen may flicker if the input signal is unstable.
 When the Function Key Guide appears, move the JOG button LEFT to select the [ ] icon and
then press the JOG button. The main screen will switch in the order
DisplayPort HDMI 1 HDMI 2.
PIP/PBP
Select the source for
each screen.
2Q
DisplayPort
HDMI 2
PIP/PBP Mode
Size
Position
Sound Source
Source
Image Size
Contrast
→
→
