Samsung UN JS9500F Series User Manual

ExplodedViewsandPartsList
LevelLoc.PartCodeDescription&SpecicationQty.SA/SNA
....50406-001689DIODE-TVS;SMH14A,15.6V ,17.9V ,1MA V ,40A,TP1SA
....50406-001691DIODE-TVS;5.5V ,7.0V ,8.5V ,0.5MA V ,TP2SA
....50501-000465TR-SMALLSIGNAL;MMBT3904,NPN,350mW,SOT-21SA
....50502-001346TR-POWER;FCX591A,PNP ,1000mW,SOT89,TR,30/1SA
....50505-002660FET-SILICON;Si2308BDS,N,60V ,2.3A,0.156oh1SNA
....50505-003224FET-SILICON;AO6405,P ,-30V ,-5A,0.052ohm,22SA
....50505-003507FET-SILICON;AO3424,N,30V ,3.8A,1.4W,SOT -24SA
....5EL020601-002037LED;SMD(TOPVIEW),BLUE,1.6x0.8mm,465/4702SA
....50801-002345IC-CMOSLOGIC;7S04,INVERTER,SOT-353,5P ,21SA
....50801-003580IC-CMOSLOGIC;TC7WB66CFK,SSOP,8P ,2.0X2.33SA
....51105-002274IC-DDR3SDRAM;K4B1G1646G-BCMA,DDR31866,3SNA
....51203-006130IC-POSI.FIXEDREG.;S-1172B25-U5T1G,SOT-81SA
....51203-007955IC-DC/DCCONVERTER;BM81222MWV ,QFN,48P ,6x2SNA
....51203-008118IC-DC/DCCONVERTER;AOZ3013PI,SO-8,8P ,4.92SA
....51203-008319IC-DC/DCCONVERTER;BM81233,QFN,32P ,5x5mm1SNA
....51203-008391IC-DC/DCCONVERTER;AOZ1269QI-02,QFN-23L,1SA
....51204-003617IC-VIDEOPROCESS;SDP1409.3,FCBGA,1023P,31SA
....5IS011209-002183IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9x11SA
....51405-001381V ARISTOR;11V ,8VDC,30A,1.6x0.8x0.9mm,TP,24SA
....52007-000039R-CHIP;0ohm,1%,1/10W,TP ,16085SA
....52007-000040R-CHIP;150ohm,1%,1/10W,TP ,16081SNA
....52007-000052R-CHIP;10Kohm,1%,1/10W,TP ,16081SA
....52007-000067R-CHIP;15Kohm,1%,1/10W,TP ,16082SNA
....52007-000070R-CHIP;0ohm,5%,1/10W,TP ,16083SA
....52007-000074R-CHIP;100ohm,5%,1/10W,TP ,16083SA
....52007-000078R-CHIP;1Kohm,5%,1/10W,TP ,16083SA
....52007-000084R-CHIP;4.7Kohm,5%,1/10W,TP ,16082SA
....52007-000109R-CHIP;1Mohm,5%,1/10W,TP ,16081SA
....52007-000137R-CHIP;2Kohm,5%,1/16W,TP ,10056SNA
....52007-000138R-CHIP;100ohm,5%,1/16W,TP ,100514SA
....52007-000140R-CHIP;1Kohm,5%,1/16W,TP ,100515SA
....52007-000143R-CHIP;4.7Kohm,5%,1/16W,TP ,100534SA
....52007-000148R-CHIP;10Kohm,5%,1/16W,TP ,100512SA
....52007-000157R-CHIP;47Kohm,5%,1/16W,TP ,10051SNA
....52007-000165R-CHIP;200Kohm,5%,1/16W,TP ,10054SNA
....52007-000171R-CHIP;0ohm,5%,1/16W,TP ,100513SA
....52007-000172R-CHIP;10ohm,5%,1/16W,TP ,10052SNA
....52007-000239R-CHIP;1.5Kohm,1%,1/10W,TP ,16083SNA
....52007-000256R-CHIP;1.6Kohm,1%,1/10W,TP ,16082SA
....52007-000287R-CHIP;100ohm,1%,1/10W,TP ,16083SNA
8Copyright©1995-2013SAMSUNG.Allrightsreserved.
