15Y BT / WIFI Combo
Waveforms of combo Module Pins (3.3V except VCC 5V)•
BT nReset
Wi-Fi nReset
(WoW ON)
Wi-Fi nReset
(WoW OFF)
3D sync in & out
BT Power_det
Wi-Fi USB DP & DM
BT wake up
VCC (5V)
BT USB DP & DM
Wi-Fi wake up
Stand by On state
High
High
High
Don't care
Don't care
60HZ signal swing
(3D mode only)
4-7
4. Troubleshooting
