7
CN502 (COMPONENT)
1 DGND 10 COMP_PR
2 AV1_CVBS_IN 11 DGND
3 DGND 12 COMP_PB
4 COMP_AV1_SL_IN 13 IDENT_COMP_Y
5 DGND 14 HP_AUD_SL_OUT
6 COMP_AV1_SR_IN 15 DGND
7 DGND 16 HP_AUD_SR_OUT
8 COMP_Y 17 IDENT_CVBS
9 DGND 18 IDENT_GENDER
8
CN804 (HDMI INPUT 4 ARC)
1 HDMI4_RX2+_HDMI 11 DGND
2 DGND 12 HDMI4_RXCLK-_HDMI
3 HDMI4_RX2-_HDMI 13 HDMI_CEC
4 HDMI4_RX1+_HDMI 14 ARC_SINGLE
5 DGND 15 HDMI4_SCL_DDC
6 HDMI4_RX1-_HDMI 16 HDMI4_SDA_DDC
7 HDMI4_RX0+_HDMI 17 DGND
8 DGND 18 HDMI4_5V_PW
9 HDMI4_RX0-_HDMI 19 HDMI4_HPD
10 HDMI4_RXCLK+_HDMI
9
CN803 (HDMI INPUT 3 SUPPORT UHD/MHL)
1 HDMI3_RX2+_HDMI 11 DGND
2 DGND 12 HDMI3_RXCLK-_HDMI
3 HDMI3_RX2-_HDMI 13 HDMI_CEC
4 HDMI3_RX1+_HDMI 14 ARC_SINGLE
5 DGND 15 HDMI3_SCL_DDC
6 HDMI3_RX1-_HDMI 16 HDMI3_SDA_DDC
7 HDMI3_RX0+_HDMI 17 DGND
8 DGND 18 HDMI3_5V_PW
9 HDMI3_RX0-_HDMI 19 HDMI3_HPD
10 HDMI3_RXCLK+_HDMI
10
CN802 (HDMI INPUT 2 DVI_PC)
1 HDMI2_RX2+_HDMI 11 DGND
2 DGND 12 HDMI2_RXCLK-_HDMI
3 HDMI2_RX2-_HDMI 13 HDMI_CEC
4 HDMI2_RX1+_HDMI 14 ARC_SINGLE
5 DGND 15 HDMI2_SCL_DDC
6 HDMI2_RX1-_HDMI 16 HDMI2_SDA_DDC
7 HDMI2_RX0+_HDMI 17 DGND
8 DGND 18 HDMI2_5V_PW
9 HDMI2_RX0-_HDMI 19 HDMI2_HPD
10 HDMI2_RXCLK+_HDMI
11
CN801 (HDMI INPUT 1 STB)
1 HDMI1_RX2+_HDMI 11 DGND
2 DGND 12 HDMI1_RXCLK-_HDMI
3 HDMI1_RX2-_HDMI 13 HDMI_CEC
4 HDMI1_RX1+_HDMI 14 ARC_SINGLE
5 DGND 15 HDMI1_SCL_DDC
6 HDMI1_RX1-_HDMI 16 HDMI1_SDA_DDC
7 HDMI1_RX0+_HDMI 17 DGND
8 DGND 18 HDMI1_5V_PW
9 HDMI1_RX0-_HDMI 19 HDMI1_HPD
10 HDMI1_RXCLK+_HDMI
12
CN2003 (USB3.0)
1 USB1_VCC_5V_PW 6 JACK3_RX+_USB30
2 JACK3_D-_USB 7 DGND
3 JACK3_D+_USB 8 JACK3_TX-_USB30
4 DGND 9 JACK3_TX+_USB30
5 JACK3_RX-_USB30
13
CN402 (IRB CONNECTOR)
1 DGND 5 N.C
2 IRB_IR_TX_1 6 IRB_JACK_ID
3 N.C 7 DGND
4 N.C
14
CN1802 (USB2.0)
1 USB2_VCC_5V_PW 3 JACK_D+_USB
2 JACK_D-_USB 4 DGND
15
CN1803 (USB2.0)
1 USB3_VCC_5V_PW 3 JACK2_D+_USB
2 JACK2_D-_USB 4 DGND
