5. Wiring Diagram
3
U1 (TCON VBY1 INPUT RX FROM FRC)
1 VIN_12V 27 GND
2 VIN_12V 28 RX3_N
3 VIN_12V 29 RX3_P
4 VIN_12V 30 GND
5 VIN_12V 31 RX4_N
6 VIN_12V 32 RX4_P
7 VIN_12V 33 GND
8 VIN_12V 34 RX5_N
9 VIN_12V 35 RX5_P
10 VIN_12V 36 GND
11 N.C 37 RX6_N
12 GND 38 RX6_P
13 GND 39 GND
14 GND 40 RX7_N
15 GND 41 RX7_P
16 HTPDN 42 GND
17 LOCKN 43 3D_EN_I
18 GND 44 SCL_I
19 RX0_N 45 B_INT
20 RX0_P 46 SDA_I
21 GND 47 N.C
22 RX1_N 48 N.C
23 RX1_P 49 AGING_ENI
24 GND 50 PDT1
25 RX2_N 51 PDT0
26 RX2_P
4
CON_12V
1 VINI_12V_PW 9 GND
2 VINI_12V_PW 10 GND
3 VINI_12V_PW 11 GND
4 VINI_12V_PW 12 GND
5 VINI_12V_PW 13 GND
6 VINI_12V_PW 14 GND
7 VINI_12V_PW 15 GND
8 N.C
5
CON_SFL(OUTPUT BLOCK)
1 AVDD_TAO_15V 35 GND
2 AVDD_TAO_15V 36 US2E_P
3 U_H 37 US2E_N
4 U_L 38 GND
5 HAVDD_TAO_7.5V 39 US2O_P
6 HAVDD_TAO_7.5V 40 US2O_N
7 L_H 41 GND
8 L_L 42 US3E_P
9 VCC_1.8V 43 US3E_N
10 VCC_1.8V 44 GND
11 OD 45 US3O_P
12 OVOFF2_-7.6V 46 US3O_N
13 N.C 47 GND
14 VON_O_28V 48 US4E_P
15 VON_O_28V 49 US4E_N
16 N.C 50 GND
17 CPV1 51 US4O_P
18 CPV3 52 US4O_N
19 STV1 53 GND
20 VCC_3.3V 54 US5E_P
21 N.C 55 US5E_N
22 VOFF1_-11V 56 GND
23 N.C 57 US5O_P
24 VCST1 58 US5O_N
25 VCS1 59 GND
26 N.C 60 US6E_P
27 VCS1 61 US6E_N
28 N.C 62 GND
29 GND 63 US6O_P
30 US1E_P 64 US6O_N
31 US1E_N 65 GND
32 GND 66 SFC1
33 US1O_P 67 GND
34 US1O_N 68 FB33_1
