5-19

5. Wiring Diagram

CON_SBR (OUTPUT BLOCK)

1 FB33_3 35 US24E_P

2 GND 36 US24E_N

3 SFC2 37 GND

4 GND 38 US24O_P

5 US19E_P 39 US24O_N

6 US19E_N 40 GND

7 GND 41 N.C

8 US19O_P 42 VCS1

9 US19O_N 43 N.C

10 GND 44 VCS1

11 US20E_P 45 VCST1

12 US20E_N 46 N.C

13 GND 47 BVOFF1_-11V

14 US20O_P 48 N.C

15 US20O_N 49 VCC_3.3V

16 GND 50 STV1

17 US21E_P 51 CPV1

18 US21E_N 52 CPV3

19 GND 53 N.C

20 US21O_P 54 BVON_O_28V

21 US21O_N 55 BVON_O_28V

22 GND 56 N.C

23 US22E_P 57 BVOFF2_-7.6V

24 US22E_N 58 OD

25 GND 59 VCC_1.8V

26 US22O_P 60 VCC_1.8V

27 US22O_N 61 L_L

28 GND 62 L_H

29 US23E_P 63 HAVDD_TAO_7.5V

30 US23E_N 64 HAVDD_TAO_7.5V

31 GND 65 U_L

32 US23O_P 66 U_H

33 US23O_N 67 AVDD_TAO_15V

34 GND 68 AVDD_TAO_15V
