Sandpiper S15 User Manual

s15nmdl3sm-REV1207 Model S15 Non-Metallic Page 2
Check Diaphragm/ Check Non-Wetted Shipping
Model Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
S15B3P1PPAS000. S 15 B 3 P 1 P P A S 0 00. 80 (36)
S15B3K1KPAS000. S 15 B 3 K 1 K P A S 0 00. 108 (49)
S15B3P2PPAS000. S 15 B 3 P 2 P P A S 0 00. 83 (34)
S15B3K2KPAS000. S 15 B 3 K 2 K P A S 0 00. 112 (51)
S15B3PGPPAS000. S 15 B 3 P G P P A S 0 00 109 (50)
S15B3KGKPAS000. S 15 B 3 K G K P A S 0 00 112 (51)
S15B3C1PCAS000. S 15 B 3 C 1 P C A S 0 00. 84(38)
S15B3C2PCAS000. S 15 B 3 C 2 P C A S 0 00. 87(39)
S15B3P6PPAV000. S 15 B 3 P 6 P P A V 0 00.
S15B3K6KPAV000. S 15 B 3 K 6 K P A V 0 00.
S15 Non-Metallic · Design Level 3 · Ball Valve
Explanation of Pump Nomenclature
Kit Options Cont.
E1.= Solenoid Kit with 24VDC
Explosion-Proof Coil
E2.= Solenoid Kit with
24VAC/12VDC Coil
E3.= Solenoid Kit with
24VAC/12VDC
Explosion-Proof Coil
E4.= Solenoid Kit with 110VAC Coil
E5.= Solenoid Kit with 110VAC, 60
Hz Explosion-Proof Coil
E6.= Solenoid Kit with 220VAC Coil
E7.= Solenoid Kit with 220VAC, 60
Hz Explosion-Proof Coil
E8.= Solenoid Kit with 110VAC, 50
Hz Explosion-Proof Coil
E9.= Solenoid Kit with 230VAC, 50
Hz Explosion-Proof Coil
SP.= Stroke Indicator Pins
Pump Brand
S= SANDPIPER
®
Pump Size
15=1 1/2"
Check Valve Type
B= Ball
Design Level
3= Design Level 3
Wetted Material
K= PVDF
P= Polypropylene
C=Conductive Polyproplyene
Diaphragm / Check Valve Materials
1= Santoprene/Santoprene
2= PTFE-Santoprene Backup/PTFE
6= PTFE Pumping, PTFE-Neoprene
Backup Driver/PTFE
B= Nitrile/Nitrile
C= FKM / PTFE
G=PTFE-Neoprene Backup/PTFE
N=Neoprene/Neoprene
U=Urethane/Urethane
Check Valve Seat
K= PVDF
P= Polypropylene
Non-Wetted Material Options
C=Carbon Filled Conductive
Polypropylene
P=40%Glass Filled Polypropylene
1=40%Glass Filled Polypropylene
w/PTFE Coated Hardware
Porting Options
A= ANSI Flange
D= DIN Flange
7= Dual Porting (ANSI)
8= Top Dual Porting (ANSI)
9= Bottom Dual Porting (ANSI)
Pump Style
D= with Electronic Leak Detection (110V)
E= with Electronic Leak Detection (220V)
M=with Mechanical Leak Detection
S= Standard
V= with Visual Leak Detection
Pump Options
0= None
1= Sound Dampening Mufer
2= Mesh Mufer
Pump Options Cont.
3= High temperature Air Valve
w/Integral Mufer
4= High temperature Air Valve
w/Sound Dampening Mufer
5= High temperature Air Valve
w/Mesh Mufer
6= Metal Mufer
Kit Options
00.= None
P0.= 0-30VDC Pulse Output Kit
P1.= Intrinsically-Safe
130VDC,110/120VAC,
220/240VAC Pulse Output Kit
P2.= 110/120 or 220/240VAC Pulse
Output Kit
E0.= Solenoid Kit with 24VDC Coil
Note: Pumps are only ATEX compliant when ordered with
wetted options C, non-wetted option C, pump options 6 or 7,
and kit options 00, P1, E1, E3, E5, E7, E8 or E9.
I M2 c T5
II 2GD T5
