s15nmdl3sm-REV1207 Model S15 Non-Metallic Page 3
Performance Curve, Model S15 Non-Metallic
Design Level 3
CAPACITY
U.S. Gallons per minute
Liters per minute
100
80
60
40
20
0
BAR
PSI
HEAD
1
2
3
4
5
6
7
0
NPSHR
FEET
METERS
30
20
10
10
6
8
2
4
00
Displacement Per Stroke:
Flow Capacity:
.43 Gallons
1.63 Liters
0-100 Gallons Per Min.
0-378 Lilters Per Min.
0 10 3020 40 50 60 80 9070 100
0 10020 150 200 250 350300
20 (34)
10 (17)
30 (51)
100 PSI (6.8 Bar)
80 PSI (5.44 Bar)
60 PSI (4.08 Bar)
40 PSI (2.72 Bar)
40 (68)
50 (85)
20 PSI (1.36 Bar)
Air Inlet Pressure
MODEL S15 Non-Metallic Performance Curve
Performance based on the following: elastomer fitted pump, flooded suction, water at ambient conditions.
The use of other materials and varying hydraulic conditions may result in deviations in excess of 5%.
