Sanyo PLC-XC50 Service Manual

-4-
Specifications
Mechanical Information
Projector Type Multi-media Projector
Dimensions (W x H x D) 410.0 mm x 85.0 mm x 262.8 mm (Not including protrusions)
Net Weight 8.82lbs (4.0 kg)
 FootAdjustment 0˚to10.0˚
Panel Resolution
LCD Panel System 0.63" TFT Active Matrix type, 3 panels
Panel Resolution 1,024 x 768 dots
Number of Pixels 2,359,296 (1,024 x 768 x 3 panels)
Signal Compatibility
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N
High Definition TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
Scanning Frequency H-sync. 15 ~ 100 KHz, V-sync. 50 ~ 100 Hz
Optical Information
Projection Image Size (Diagonal) Adjustable from 40" to 300"
Projection Lens F 1.60-1.76 lens with f =22.33 mm ~ 26.80 mm with manual zoom and focus
Throw Distance 4.6' ~ 41.3' (1.4 m ~ 12.6 m)
Projection Lamp 220W
Interface
Video Input Jack RCA Type x 1
S-video Input Jack Mini DIN 4 pin x 1
Audio Input Jacks RCA Type x 2
Computer Input 1/DVI-I Digital/Analog RGB (DVI-I ) Terminal x 1
Computer Input 2/Component Input Analog RGB (Mini D-sub 15 pin) Terminal x 1
Monitor Output Analog RGB (Mini D-sub 15 pin) Terminal x 1
Computer2/ Component Audio Input Jack
Mini Jack (stereo) x 1
Computer1 Audio Input Jack Mini Jack (stereo) x 1
Control Input Mini D-sub 9 pin x 1
Audio Output Jack Mini Jack (stereo) x 1 (Variable)
Audio
Internal Audio Amp 7.0 W RMS
Built-in Speaker 1 speaker, ø1.46" (37mm)
Power
Voltage and Power Consumption AC 100 ~ 120 V (3.4A Max. Ampere), 50/60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (1.7A Max. Ampere), 50/60 Hz (Continental Europe and The U.K.)
Operating Environment
 OperatingTemperature 41˚F~95˚F(5˚C~35˚C)
 StorageTemperature 14˚F~140˚F(-10˚C~60˚C)
Remote Control
Battery AA or LR6 1.5 V ALKALINE TYPE x 2
 OperatingRange 16.4'(5m)/±30˚
Dimensions 1.9" (W) x 0.87" (H) x 5.7" (D) (49 mm x 22 mm x 145.3 mm)
Net Weight 3.53 oz (100 g) (including batteries)
●The specifications are subject to change without notice.
●LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a
tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.
