Sanyo PLC-XU86 User Manual

-36-
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 544 OverScan RGB 480p
0 Total Dots(HTOTAL) AD9882 1200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 956 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 194 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 48 Vertical Back Porch
4 Disp Line (VRES) PW186 458 Vertical Resolution
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 546 OverScan RGB 575p
0 Total Dots(HTOTAL) AD9882 1200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 942 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 210 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 62 Vertical Back Porch
4 Disp Line (VRES) PW186 540 Vertical Resolution
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 548 OverScan RGB 720p
0 Total Dots(HTOTAL) AD9882 1650 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1250 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 308 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 34 Vertical Back Porch
4 Disp Line (VRES) PW186 702 Vertical Resolution
5 Clamp Pos AD9882 48 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 550 OverScan RGB 1035i
0 Total Dots(HTOTAL) AD9882 2200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 92 Vertical Back Porch
4 Disp Line (VRES) PW186 1012 Vertical Resolution
5 Clamp Pos AD9882 48 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 552 OverScan RGB 1080i 50Hz
0 Total Dots(HTOTAL) AD9882 2640 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 54 Vertical Back Porch
4 Disp Line (VRES) PW186 1052 Vertical Resolution
5 Clamp Pos AD9882 48 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 554 OverScan RGB 1080i 60Hz
0 Total Dots(HTOTAL) AD9882 2200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 56 Vertical Back Porch
4 Disp Line (VRES) PW186 100 Vertical Resolution
5 Clamp Pos AD9882 48 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 560 OverScan Scart 480i
0
1 Disp Dots (HRES) PW186 676 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 74 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 52 Vertical Back Porch
4 Disp Line (VRES) PW186 450 Vertical Resolution
5
6
Group 562 OverScan Scart 575i
0
1 Disp Dots (HRES) PW186 648 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 100 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 66 Vertical Back Porch
4 Disp Line (VRES) PW186 528 Vertical Resolution
5
6
