Sanyo PLC-XU86 User Manual

-35-
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
5
6
Group 520 OverScan HDTV 480i
0
1 Disp Dots (HRES) PW186 670 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 76 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 48 Vertical Back Porch
4 Disp Line (VRES) PW186 458 Vertical Resolution
5
6
Group 522 OverScan HDTV 575i
0
1 Disp Dots (HRES) PW186 660 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 62 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 62 Vertical Back Porch
4 Disp Line (VRES) PW186 542 Vertical Resolution
5
6
Group 524 OverScan HDTV 480p
0 Total Dots(HTOTAL) AD9882 1317 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1050 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 212 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 48 Vertical Back Porch
4 Disp Line (VRES) PW186 460 Vertical Resolution
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 526 OverScan HDTV 575p
0 Total Dots(HTOTAL) AD9882 1253 AD9882 PLL Div
1 Disp Dots (HRES) PW186 988 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 216 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 62 Vertical Back Porch
4 Disp Line (VRES) PW186 540 Vertical Resolution
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 528 OverScan HDTV 720p
0 Total Dots(HTOTAL) AD9882 1650 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1250 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 308 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 34 Vertical Back Porch
4 Disp Line (VRES) PW186 702 Vertical Resolution
5 Clamp Pos AD9882 42 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 530 OverScan HDTV 1035i
0 Total Dots(HTOTAL) AD9882 2200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 90 Vertical Back Porch
4 Disp Line (VRES) PW186 1012 Vertical Resolution
5 Clamp Pos AD9882 50 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 532 OverScan HDTV 1080i 50Hz
0 Total Dots(HTOTAL) AD9882 2640 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 56 Vertical Back Porch
4 Disp Line (VRES) PW186 1052 Vertical Resolution
5 Clamp Pos AD9882 50 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 534 OverScan HDTV 1080i 60Hz
0 Total Dots(HTOTAL) AD9882 2200 AD9882 PLL Div
1 Disp Dots (HRES) PW186 1872 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 252 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 56 Vertical Back Porch
4 Disp Line (VRES) PW186 1050 Vertical Resolution
5 Clamp Pos AD9882 50 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 540 OverScan RGB 480i
0 Total Dots(HTOTAL) AD9882 780 AD9882 PLL Div
1 Disp Dots (HRES) PW186 610 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 134 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 48 Vertical Back Porch
4 Disp Line (VRES) PW186 460 Vertical Resolution
5 Clamp Pos AD9882 1 AD9882 Clamp Placement
6 Clamp Width AD9882 31 AD9882 Clamp Duration
Group 542 OverScan RGB 575i
0 Total Dots(HTOTAL) AD9882 944 AD9882 PLL Div
1 Disp Dots (HRES) PW186 718 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 178 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 66 Vertical Back Porch
4 Disp Line (VRES) PW186 536 Vertical Resolution
