-34-
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
2 OFFSET AREA H START PW186 25 0 - 4095 Black Level Acquire area H-Start Position
3 OFFSET AREA V START PW186 500 0 - 4095 Black Level Acquire area V-Start Position
4 GAIN AREA H START PW186 975 0 - 4095 White Level Acquire area H-Start Position
5 GAIN AREA V START PW186 500 0 - 4095 White Level Acquire area V-Start Position
6 Image AREA H WIDTH PW186 13 0 - 4095 Black/White Level Acquire area
7 Image AREA V HIGHT PW186 9 0 - 4095 Black/White Level Acquire area Height
8 OFFSET target PW186 1 0 - 127 Target for Black Level Adj.
9 OFFSET torelance PW186 1 1 - 127 Allowence Range for Black Level Adj
10 GAIN target PW186 244 0 - 255 Target for White Level Adj.
11 GAIN torelance PW186 1 1 - 255 Allowence Range for White Level Adj
12 Offset Area Average [ Red ] PW186 0 0 - 255 Read Only
13 Offset Area Average [ Green ] PW186 0 0 - 255 Read Only
14 Offset Area Average [ Blue ] PW186 0 0 - 255 Read Only
15 Gain Area Average [ Red ] PW186 0 0 - 255 Read Only
16 Gain Area Average [ Green ] PW186 0 0 - 255 Read Only
17 Gain Area Average [ Blue ] PW186 0 0 - 255 Read Only
18 Image LevelUpdate [ OFFSET ] PW186 0 0 - 255 Upadte item 12/13, Link to item 14
Group 300 General DeInterlacer
1 3:2 PullDown Mode PW186 3 1 - 3
bit 0 : Global Motion Enable (FILMODEN23 GMD)
bit 1 : Video Motion(VOFMODEN)
2 Detect Film Mode Enable PW186 0 0 - 2
0 : 2:3pull down & 2:2pull down, 1 : 2:3pull down, 2 : 2:2pull down
* Adjust at Film Mode with Menu
Group 301 Motion Adaptive
0 Motion Adaptive Weight Value L1 PW186 30 0 - 255 KDEINT
1 Motion Adaptive Weight Value L2 PW186 0 0 - 255 KDEINT
2 Motion Adaptive Weight Value FILM PW186 30 0 - 255 KDEINT
Group 302 Low Angle Interporation (LAI)
0 Angle Interpolation Level L1 PW186 4 0 - 4
1 Angle Interpolation Level L2 PW186 2 0 - 4
2 Angle Interpolation Level FILM PW186 4 0 - 4
Group 311 Noise Reduction L1
0 Noise Pixel Range PW186 1 0 - 3 <NSRANGEY> / <NSRANGEUV>
1 Noise Region 0 PW186 12 0 - 1023 <NSREGIONY0> / <NSREGIONUV0>
2 Noise Region 1 PW186 24 0 - 1023 <NSREGIONY1> / <NSREGIONUV1>
3 Noise Region 2 PW186 40 0 - 1023 <NSREGIONY2> / <NSREGIONUV2>
4 Noise Gain Level PW186 90 0 - 1023 <NSFILTERY**> / <NSFILTERUV**>
Group 313 Noise Reduction L2
0 Noise Pixel Range PW186 1 0 - 3 <NSRANGEY> / <NSRANGEUV>
1 Noise Region 0 PW186 12 0 - 1023 <NSREGIONY0> / <NSREGIONUV0>
2 Noise Region 1 PW186 24 0 - 1023 <NSREGIONY1> / <NSREGIONUV1>
3 Noise Region 2 PW186 40 0 - 1023 <NSREGIONY2> / <NSREGIONUV2>
4 Noise Gain Level PW186 110 0 - 1023 <NSFILTERY**> / <NSFILTERUV**>
Group 320 2:2 Pull Down
0 22Film Mode Sensitivity PW186 4 1 - 5 Film Detection Sensitivity <FILMSTVT22>
1 22Film Mode Threshold Low PW186 80 0 - 32767 <FILMTHRD22A>
2 22Film Mode Threshold High PW186 120 0 - 32767 <FILMTHRD22B>
3
4
5
6 Video Motion Window Start X PW186 10 0 - 2047
Window Setting of 22PullDown & Video Motion Sum calib.
7 Video Motion Window StopX PW186 10 0 - 2047
8 Video Motion Window Start Y PW186 10 0 - 1023
9 Video Motion Window StopY PW186 10 0 - 1023
10
Group 321 3:2 PullDown
0 Global Motion Sensitivity PW186 4 1 - 5 Film Detection Sensitivity <FILMSTVT23>
1 Video Motion Sensitivity PW186 4 1 - 5 Film Detection Sensitivity <VOFSTVT>
2 Video Motion Threshold Low PW186 120 0 - 32767 <VOFTHRDA>
3 Video Motion Threshold High PW186 180 0 - 32767 <VOFTHRDB>
4
5 23Film Mode Threshold PW186 100 0 - 32767 <FILMTHRD23>
6 Global Motion Window Start X PW186 10 0 - 2047
Window Setting of Global Motion Sum Calib.
7 Global Motion Window Stop X PW186 10 0 - 2047
8 Global Motion Window Start Y PW186 10 0 - 1023
9 Global Motion Window Stop Y PW186 10 0 - 1023
10 GMDLNTHR PW186 100 0 - 2047 GMDLNTHR
Group 500 OverScan Video 480i
0
1 Disp Dots (HRES) PW186 668 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 82 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 52 Vertical Back Porch
4 Disp Line (VRES) PW186 450 Vertical Resolution
5
6
Group 502 OverScan Video 575i
0
1 Disp Dots (HRES) PW186 664 Horizontal Resolution
2 Horz Back Porch (HPOS) PW186 92 Horizontal Back Porch
3 Vert Back Porch (VPOS) PW186 62 Vertical Back Porch
4 Disp Line (VRES) PW186 534 Vertical Resolution
