Sanyo PLV-Z2000 Service Manual

-73-
Chassis Block Diagrams
IC301
SCAN
CONVERTER,
SYSTEM
CONTROL
<PW392 >
B-LCD
PANEL
G-LCD
PANEL
R-LCD
PANEL
K35R K35G K35B
DR_1/2/3 DB_1/2/3DG_1/2/3
IC4401
COLOR
MANAGER
<EP2C35>
IC801
FLASH ROM
<S29GL064>
IC1391
EEPROM
IC3401
SDRAM
<MSM56V16160>
MAIN BOARD
PW_DR
PW_DG
PW_DB
DR
DG
DB
DHS,DVS,DCLK
PW_HS,PW_VS
PW_CLK
IC8001
HDMI
RECEIVER
<SII9125>
HDMI1
COMPONENT_1
Y/Cb/Cr
COMPONENT_2
Y/Cb/Cr
Y
D5
Cb
Cr
Y
Cb
Cr
COMPUTER S-VIDEO VIDEO
S_Y
Y/C
SOG
S_C
CV
PC_HS
PC_VS
PC_RGB
PC_H=SCART_CV
PC_RGB/SCART
SIOUTR,G,B
YCbCr_1
D5_LINE
FOR JAPAN
MODEL ONLY
YCbCr_2
ADHS
ADVS
HDMI1
TMDS
HDMI2 HDMI2
TMDS
SIHS/SIVS
D-SUB_15
IC401
DIGITAL
GAMMA
<L3E07120>
IC561
S&H
BLUE
<L3E07200>
IC531
S&H
GREEN
<L3E07200>
IC501
S&H
RED
<L3E07200>
1
pin
R
G
B
H_SYNC
V_SYNC
RGB
R
G-ON SYNC
B
-
-
R
G
B
CV_SYNC
-
RGB(SCART)
D-SUB_15 Input Signal
2
3
13
14
● Video signal processing circuit and LCD panel driving circuit

Sanyo PLV-Z2000 Specifications

General

Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Focus	Manual
Digital zoom	2 x
Focal length range	22.6 - 45.3 mm
RS-232 ports	1
Dimensions (WxDxH)	400 x 346 x 146 mm
Power requirements	100 - 240V
Connectivity technology	Wired
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Full HD	Yes
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	2
Noise level	26 dB
Power consumption (typical)	240 W

Weight and Dimensions

Weight	7300 g
