-88--88-
Control Port Functions
67 PFAIL_DCT2 FROM : POWER_FAIL I
282 1.0VGA_DETECT I
179 S1.2V_DETECT I
281 THERM1 FROM : EXT. TEMP SENSOR1 I
68 THERM2 FROM : EXT. TEMP SENSOR2 I
180 IC301_ADC7 O
69 CPU_ADC_IN I
380 PW_DHS O
285 PW_DVS O
381 PW_DCLK O
286 PW_DEN O
291 PW_TXD I/O
386 PW_RXD I/O
292 WIRELESS_REMOTE I
293 IR RCVR2 I
294 MNI_RST FROM : K3451 P17 & MNISW 301 I
475 SIINT I
479 ROMWE O
84 ROMOE O
194 IC301_AJ6 O
399 PC_V I
98 PC_H I
209 CR1 I
101 Y1 I
210 Y1 I
311 CB1 I
102 CR2 I
103 Y2 I
211 Y2 I
212 CB2 I
104 SCART_CV I
214 PC_R/SCART I
315 PC_SOG I
106 PC_G/SCART I
215 PC_B/SCART I
108 S_C I
318 S_Y I
109 CVBS I
219 D4_LINE3 I
320 D4_LINE2 I
413 D4_LINE1 I
222 PW_RST FROM : K3451 P18 I
Pin No. Name Function Name Function Polarity I/O
I/O Port Table of Main CPU (IC301, PW392)_CONTINUE
