7. EXPLANATION OF PARAMETERS
7－50
Mode Page
Abbre-
viation
Name and description
Standard
value
Unit
Setting
range
Remarks
2 3 Func2 Amplifier function select 2
• A desired monitor output method or
regenerative resister OL time can be
selected.
0010-
0000
0, 1 ( 1)
( 3)
Regenerative resistor OL time select 2 4
Monitor 2 out
p
ut
p
olarit
y
Alarm out
p
ut method
0 Positive output at forward revolution
1 Negative output at forward
Monitor 1 out
p
ut
p
olarit
y
Func2
012
345 6
7
0 Positive output at forward revolution
1 Negative output at forward
0 Negative/positive output
1 Absolute value output
Monitor 1 out
p
ut absolute value
0 Negative/positive output
1 Absolute value output
Monitor 2 out
p
ut absolute value
0 Regenerative resistor allowable
effective power: 20 W or lower
1 Regenerative resistor allowable
effective power: Higher than 20 W
0 Enabled
1 Disabled
Speed control error (SE) detection
0 CODE
1 BIT
0 Turned off at an alarm
1 Turned on at an alarm
Alarm out
p
ut lo
g
ic
1 If bit 7 is set at "1", an alarm will not be indicated for a CPU error.
2 Bit 4 cannot be changed unless the control power is turned off.
3 Forward revolution refers to the counterclockwise revolution when viewed from the
load (motor shaft) side.
4 The 15 A and 30 A capacity amplifiers do not have built-in regenerative resistors.
• Bit 4 shall be set according to the permissible effective power of the external
regenerative resistor used.
The 50 A capacity amplifiers have built-in regenerative resistor.
• When using a built-in regenerative resistor, set bit 4 at “0”.
• When using an external regenerative resistor, set bit 4 according to the
permissible effective power of the resistor.
