APPENDICES
English 220
Camera connectors
* Via the docking station
[COMPONENT/
AV] (480p/
1080i/720p
output) terminal*
Regrouped jack
Audio
output
265mVrms (–9dBs), 12kΩ or less, stereo
Video
output
1.0 Vp-p, 75 Ω unbalanced, sync negative,
composite video
NTSC color TV system/PAL color TV system
(switchable from the Option Screen)
S-video
output
Y signal: 1.0 Vp-p, 75 Ω, unbalanced, sync
negative
C signal: 0.286 Vp-p, 75 Ω, unbalanced
NTSC color TV system/PAL color TV system
(switchable from the Option Setting Menu)
For 480p/1080i/720p video output
Y signal: 1.0 Vp-p/75 Ω unbalanced, tri-level sync
Pb and Pr signals: 0.7 Vp-p/75 Ω unbalanced
[HDMI] terminal* Video output
Total number of scan lines (effective number of scan
lines): 750p (720p)/1125i (1080i)/525p (480p)
Audio output: L-PCM 48 kHz sampling
[USB] terminal* USB 2.0 High-speed
[MIC]
(microphone
input) terminal
ø2.5 mm stereo mini jack (converts to a ø3.5 mm
stereo mini jack by the supplied microphone connection
cable), 2 kΩ.
Sensitivity: less than –42 dB (plug-in power type
microphone)
Headphone jack ø3.5 mm mini-jack (stereo headphone jack, impedance
16 Ω to 32 Ω)
Audio
output
310 mVrms (–8 dBs), 47 kΩ, stereo
DC IN (external
DC power input)
terminal
DC 5 V (for exclusive use with the supplied AC adaptor
[VAR-G8])
