30
Application Programs
Counting
Purpose
With this application program you can determine
the quantity of a number of parts that each have
approximately equal weight.
Available Features
– Reference sample quantity can be changed either
in the operating menu or during weighing
– Save the active weight value to have it loaded
as the preset reference sample quantity next time
you initialize the counting application
– Re-initialize without quitting the program
– Have the average piece weight automatically
output to the data interface port when the
application is initialized, if the menu code for
“Printout with data ID codes” is set
– Press w to toggle the display between piece
count and weight
Factory Settings
Display accuracy: Standard resolution (3 2 1)
Reference sample quantity: 10 (3 3 2)
Preparation
Select the “Counting” application in the operating
menu:
$ Turn off the scale: Press e
● Turn on the scale: Press e; while all segments
are lit, press the ) key briefly
To Next Page
