7 Technical Data
7.1 General Data
Specification Unit Value
Scale
Supply voltage Only via USB interface or Sartorius AC adapter YEPS01-USB
Input voltage V
DC
+5.0
Power consumption W 2.0
Further data IP40 in accordance with EN 60529/IEC 60529
Ambient conditions
The technical specifications apply under the following ambient conditions:
Environment For indoor use only
Ambient temperature* °C +10 to +30
Operational capability °C Guaranteed between +5 and +45
Storage and shipping °C -10 to +60
Relative humidity % 15 to 80 for temperatures up to 30°C non-condensing,
decreasing linearly to 50% relative humidity at 40°C
Interface connection USB, type B (virtual serial interface)
Format 7-bit ASCII, 1 start bit, 1 or 2 stop bits
Parity Even, odd, none
Transmission rate 600 to 57,600bps
Handshake Software or hardware
Electromagnetic compatibility In accordance with EN 61326-1/IEC61326-1 Electrical equipment for
measurement, control and laboratory use – EMC requirements – Part 1:
General Requirements
Interference resistance Basic requirements
Transient emissions Class B
Suitable for use in residential areas and areas that are connected to a
low voltage network that also supplies residential buildings.
Verified scales in accordance with EU requirements comply with the
requirements of Council Directive 2014/31/EU with EN 45501:2015 and
OIML R76:2006.
* For verified scales in accordance with EU requirements, refer to the
information on the scale.
** For verified scales in accordance with EU requirements, the legal
regulations apply.
Available application programs Recalculation, formula
Power supply YEPS01-USB (optional)
USB power plug Type FSP007-P01P (manufacturer’s designation)
Primary
100–240 V~, ±10%, 50–60 Hz, ±5%, < 0.2 A
Secondary 5.2 V
DC
, ± 5%, 1.4 A (max.)
Further data Protection class II
IP40 in accordance with EN 60529/IEC 60529
Installation Instructions EVO1S1 | SPO1S1 9
English
