32 Cubis MSE Operating Instructions
Operation
Opening and closing the motorized draft shield (optional)
*
If your balance is equipped with a motorized draft shield, you can use the * key
to open and close the draft shield doors�
Models with the analytical draft shield:
The * key can be set, for example, so that it opens and closes the right and
top door (for right-handed people)� The opening width (entirely or partially) of the
sliding panels can also be defined� You can configure these settings manually on
the draft shield itself (see next section “Learning Function" below)�
Assigning Opening Functions to the * Key (Learning Function)
The balance must be turned on�
t Close all draft shield doors�
t Manually operate the door you want to assign to the * key: Push the right
door open as far as you want it to opened (entirely or partially)�
t Press the * key�
y The door will close again� Now you have configured the * key so that, when
pressed, it opens or closes the right door�
t Proceed in the same way to configure the left door�
h
Using the same method, you can assign the upper door to this key� You can also
configure one key to move both doors by manually opening both doors during
setup before pressing the * key�
Models with a rotation draft shield (MSx6.6S/3.6P/2.7S):
t Set the opening width: manually select the desired opening angle
t 1) Open to the previously selected opening angle:
Press the * key
2) Close: Press the * key
100°
180°
260°
0°
