22
Service Manual Signum
Working with the Service Mode
1-9-4 Calibration/Adjustment with an Internal Weight
2)
– Select weighing platform »WP1«.
– Press the ) key to access the number menu.
– Press the ) and k ) keys repeatedly to select menu code »1-9-4«
(Internal calibration/adjustment
2)
). Then briefly press the ( ) key to
confirm.
– You can jump to the first columns in the number menu by pressing the ( key.
– To store the selected menu, press and hold the ) key.
– After taring or zeroing the display of the scale, press and hold the J key until
»C.INTERN« is displayed.
Press the J key to continue the calibration/adjustment routine.
– The motorized, internal calibration weight is placed on the scale and then
removed.
– After approx. 2 seconds, the difference in the current calibration value is
displayed.
– Press the J key to store the current calibration weight. Afterwards, the scale
returns to the normal weighing mode.
2)
Only performed on scales with an internal calibration weight.
3)
Only displayed if menu code »1-10-2 (Calibration with manual adjustment) has been selected
cal_def.eps
Display_WP1_Serv.eps
Menu-194.eps
cal_ci.eps
+00015.eps
+00000.eps
3)
