Sartorius Signum 1 - Additional Models and Information; Design 4; Design 5; Design 6

9
Service Manual Signum
Introductory Remarks
PW_Sys_GHS_04.eps
PW_Sys_DMS_05.eps
PW_Sys_DMS_06.eps
Model Design 4 System
Supreme weighing system:
Narrow forked-lever system (to the right)
With built-in motorized calibration weight
Nominal load 40kg
Design 5
Regular weighing system:
Strain gauge technology (to the right)
Without built-in motorized calibration
weight PW15-EX | Nominal load up to 30kg
Design 6
Regular weighing system:
Strain gauge technology (to the right)
Without built-in motorized calibration weight
PW10-EX | Nominal load up to 100kg
