with master user code or with service code, and next the “Events” function should be called.
The way of viewing is described in section HOLD DOWN USER FUNCTIONS.
6.12 T
ESTING OUTPUTS AND LED INDICATORS
[CODE][
*
][11][#]
The function makes it possible to check the current logical status of the control panel outputs
(active/inactive), as well as functioning of the outputs and devices connected to them. After
calling the function from the LED type keypad, the control panel will indicate the current
status of outputs on LEDs with corresponding numbers: 1 – OUT1, 2 – OUT2, 3 – OUT3. The
lit up LED means active output, the extinguished LED inactive output. In the LCD keypad, the
status of outputs is displayed on the first three characters of the second line of the display.
The active outputs are indicated by displaying a corresponding digit (1, 2, or 3), and the
inactive - by displaying a dot. In order to carry out the functional test of the output
(arm/disarm), press the key with the number of specified output. By repeatedly pressing the
same key the output status will be toggled to the opposite one. Activation / deactivation of an
output is acknowledged by three short beeps.
Additionally, the function enables the LEDs installed in the keypad to be checked for proper
functioning. Pressing the key [0] when the function is active will light up all the LEDs (indicators
and keypad backlighting) in all keypads connected to the alarm control panel. Pressing any key
with other digit will extinguish all the LEDs which are inactive at the moment.
After quitting the function key [#] or [
*
], the control panel will restore the previous status of the
outputs, from before calling the function.
6.13 S
ERVICE ACCESS
[CODE][
*
][12][#]
The function, which is available to the master user, allows the installer to access the system
by using the service code. It requires some data to be entered i.e. the number of hours during
which the control panel service mode will be available to the installer / service (up to 99).
After this time period expires, the access will be blocked. In order to program the access
time, call the function, enter two digits to indicate the number of hours (using zero in the
beginning for numbers smaller than 10) and press the [#] key.
Two zeros entered with this function (for the number of hours) automatically block the access.
The access time countdown is running, whether the service mode is active or not. The countdown
can only be interrupted by disconnection of power supply (230V mains and/or battery). By calling
this function you can check how much time remains until the access is blocked by the service code
- the 00 indication means that countdown of the last hour is going on.
