CA-5 SATEL
5
• If, when the control panel is in armed mode, an
E
NTRY
/E
XIT
or D
ELAYED
zone will be
violated as the first one, and then another zone will set off alarm, then the memory of the
first alarm will be assigned to the zone which was violated first.
• If, after violation of an
E
NTRY
/E
XIT
or D
ELAYED
zone, the system will be disarmed without
setting off alarm, then the memory of the first alarm (violation) will be automatically
cleared.
• POWER (green) – indicates the control panel power supply status:
− on - power supply and battery OK
− blinking - low battery
− off - no mains power
• TROUBLE (yellow) – blinks when the control panel detects a technical problem or
a monitoring problem. The LED will go out when the trouble cause is removed or after the
function of checking the current troubles is performed (key 7 function).
• PROGRAM (red) – indicates the control panel operation in programming mode:
− on – service mode (additionally, a short beep every 3 seconds) – pressing successively
the [0][#] keys will result in return to the normal operation mode
− slowly blinking – user function mode
− fast blinking – programming of a function has been called (service or user); the alarm or
trouble viewing function has been activated (HOLD DOWN user function).
4.2 S
TATUS OF CONTROL PANEL ARMED ZONES IN
LCD
KEYPAD
The first five characters (counting from the left) in the LCD display lower line indicate the
state of detectors attached to the control panel armed zones. Stated below are the symbols
which may be displayed there, as well as their respective meanings:
- the zone is free (not violated)
¦ - the zone is violated
- 2EOL zone tamper violated
a - the zone caused an alarm condition (alarm memory)
A - the zone has been violated or caused alarm as the first one (counting from the
moment of ending the exit delay countdown after arming – see notes in the section
on LED
FUNCTIONS
)
s - zone triggered the tamper alarm (memory of 2EOL zone tamper alarm)
S - tamper alarm caused as the first one (for 2EOL zone)
b - the zone is bypassed
4.3 C
ONDITIONS SIGNALED ACOUSTICALLY IN THE KEYPAD
The signals generated to confirm the operation on the keypad:
• one short – confirmation of pressing a key; activation of the review function in the keypad
(HOLD DOWN: 5, 6, 7)
• three short - confirmation of entering the mode of user functions programming;
deactivation of the chime signaling in the keypad (key 8), reset of the D
URESS ALARM
output
activity,
• one long (lasting approx. 1.5s) - refusal to arm due to violation of some zones which are
not supposed to be violated at the moment of arming,
• two long - a wrong access code, canceling a function or incorrect data for a function,
