User Manual CA-5
6
• three long - an attempt to arm the system when the control panel is not ready for the job
(violated zones with the activated option of „priority” - see „Arming”), refusal to enter the
function,
• four short, one long – arming/disarming, entering the service mode, successful
completion of function programming, activating the chime signaling in the keypad.
• six short – partial arming (there are some zones bypassed).
System events signaling:
• continuous signal – alarm,
• intermittent signal - fire alarm,
• one short signal every 3 seconds - entry time countdown; service mode (with the
PROGRAMMING LED on),
• one long signal every 3 seconds - exit delay countdown,
• five short signals - violation of the "CHIME" type zone.
Which events are to be signaled acoustically should be determined by the installer.
4.4 E
VENTS SIGNALED ON THE
OUT1
OUTPUT
The installer may activate the signaling of arming/disarming and alarm clearing on the OUT1
output. If this output controls the siren operation, it will generate short sounds (in much the
same way as in the car alarm systems). The signals have the following meanings :
• one short sound – arming,
• two short sounds – disarming,
• four short sounds – clearing the alarm or disarming and clearing the alarm.
Additionally, the OUT1 output signals the typical situations for the security system:
• continuous signal – burglary alarm,
• intermittent signal 1s/1s – fire alarm.
The installer may select an identical manner of signaling for the fire alarm as for the burglary
alarm (i.e. the continuous signal).
4.5 U
SER ACCESS CODES
For everyday operation of the system it is necessary to know the user access code (the
access code is a sequence of 4 to 8 digits within the range of 0-9).
To enter the access code in the control panel, press the corresponding keys on the keypad in
the order of the code digits and finish the full sequence by pressing the [#] or [
*
] keys (as may
be required). The control panel comes with the following factory settings:
master user access code: 1234;
service code: 12345.
By using the master user code you can program 5 additional user access codes, or to
delete them if they were programmed before.
The installer can assign specific authority levels to some of the access codes to distinguish
them from the other user codes:
• Access code No. 4 – action under duress (disarming or alarm clearing by means of this
code results in sending a special code to the monitoring station, and activating the D
URESS
ALARM
output)
− access code cannot be changed with the user function 1;
− the code does not reset activity of the D
URESS ALARM
output.
