10 ETHM-1 Plus SATEL
You can enter values from 1 to 65535. The value must be different from that entered for
the other ports. Default value: 7091.
Wrong login
Log event [Fail. – event] – if this option is enabled, all unauthorized attempts to connect to
the module are written to the event log.
Alarm [Fail. – alarm] – if this option is enabled, any unauthorized attempt to connect to the
module will trigger the tamper alarm. The option is available, if the LOG EVENT option is
enabled.
Integration
Integration [Integrate] – if this option is enabled, the module can be used for integration of
the alarm control panel with other systems.
Encrypted integration [Coded integr.] – if this option is enabled, communication with other
systems is encrypted. The integration encryption key should be programmed in the control
panel:
LCD keypad: SERVICE MODE OPTIONS INTEGRATE KEY,
DLOADX program: “Options” window “Service” tab.
Port [Port (integr.)] – number of the TCP port used for integration. You can enter values from
1 do 65535. The value must be different from that entered for the other ports. Default
value: 7094.
PING test
PING test – if this option is enabled, the module can perform a communication test using the
ping command sent to the indicated network device. Parameters related to the
communication test should be programmed in the control panel:
LCD keypad: SERVICE MODE OPTIONS PING TEST,
DLOADX program: “Structure” window “Hardware” tab “Keypads” branch.
SATEL server
Connection via Satel server [SATEL server] – if the option is enabled, the module connects
to the SATEL server and the communication via the SATEL server with the control panel
can be established (Connection Setup Service). This way of communication requires no
additional configuring of the network device through which the module connects to the
public network.
For establishing communication with the SATEL server, the DNS server must be used.
For communication via the SATEL server, the ports of 1024-65535 range are used as
outgoing ports. These ports must not be blocked.
Push notifications – if this option is enabled, the INTEGRA CONTROL application can
provide information about alarm system events by means of push notifications.
Information
MAC – module hardware address.
ID – individual ID number assigned to the module by the SATEL server.
If the module is to be used in another alarm system, the hitherto used ID number must
be deleted. You should do it after connecting the module to the new control panel and
establishing connection with the SATEL server, using the CHANGE ID function available
from the keypad (SERVICE MODE STRUCTURE HARDWARE  LCD KEYPADS 
SETTINGS [module name] CHANGE ID), if the control panel is connected to the

Satel ETHM-1 Plus Specifications

Power

supply voltage	12 V DC ±15%
standby current consumption	70 mA
maximum current consumption	80 mA

Operating Environment

environmental class	II
operating temperature range	-10 to +55 °C
maximum humidity	93±3%

Weight and Dimensions

dimensions	68 x 140 mm
weight	64 g
