34 ETHM-1 Plus SATEL
downloaded from the internet store “Google play” (Android system devices) or “App Store”
(iOS system devices). On the www.satel.eu website, you will find links to the locations from
which the applications can be downloaded.
The INTEGRA CONTROL app can connect directly to the ETHM-1 Plus module (the module
must have a public IP address) or establish connection via the SATEL server (Connection
Setup Service – the module requires no public IP address).
Required module settings for both ways of establishing connection:
 enabled INTEGRA CONTROL option,
 programmed data encryption key (GUARDX KEY).
 enabled CONNECTION VIA SATEL SERVER option, if connection is to be established via the
SATEL server,
 programmed the number of TCP port which will be used for communication, if connection
is to be established directly with the module.
To configure settings for communication via SATEL server in the INTEGRA CONTROL app,
you can use the QR code (see p. 11). If the communication settings are configured in one
mobile device, you can easily copy them to another mobile device. You just need to display
the QR code on the device in which the settings for communication with the given module are
already configured and read it on another device.
7.3.1 Configuring the settings in INTEGRA CONTROL application (Android)
When you launch the application for the first time, the “Add control panel” screen will be
displayed. It allows you to configure the settings required for establishing connection to the
control panel.
1. Enter the name for alarm system. The name helps to identify the system when the
application is in use (you can define settings for multiple alarm systems).
2. If you want to use another communication method than the one set by default, tap on the
screen in the “Communication way” area and make your selection.
3. Enter parameters required for the selected method of communication:
 direct communication with the module: module network address, TCP port number and
data encryption key (GUARDX
KEY),
 communication via SATEL server: module MAC address, module ID and data
encryption key (GUARDX
KEY). If you wish to enter these parameters by using the QR
code, tap and read the QR code.
The alarm system user can check the module network address, MAC address and ID
using the LCD keypad (IP/MAC/IMEI/ID user function available in the TESTS submenu
– see the control panel user manual).
4. Define how the macro commands should be handled. Default settings provide for
importing macro commands from the module (they will be downloaded during the first
connection). If the macro commands are not to be imported or are to be imported from
file, touch the screen in the “Macros” area and change the settings. If you select import
from file, you will have to indicate location of the file containing macro commands.
5. Tap to save settings.
