SATEL ETHM-1 Plus 11
SATEL server. Having deleted the old ID number, the control panel will receive a new
one. The INTEGRA CONTROL applications using the old ID number will be unable to
connect to the control panel.
IP – local address / public address of the module.
[GSM signal] – information about GSM signal strength and GSM network operator. The
information is displayed when the INT-GSM module is connected to the ETHM-1 Plus
module (module is identified as “ETHM+GSM”).
QR-code – click the button to open the window in which the QR code is displayed. The QR
code contains information required when configuring settings of communication through
the SATEL server. You can read the QR code by using a mobile device or export to the file
and transmit to the users. The QR code facilitates configuring the INTEGRA CONTROL
application settings.
Refresh – click to refresh all information.
LAN uplink loss report delay – if the Ethernet network is not available for a preset period of
time, the module will report a trouble. A delay in reporting the trouble prevents sending
information about short-time loss of Ethernet connectivity.
6.1.2 INT-GSM functions
These settings apply to the INT-GSM module. They are available if the INT-GSM module is
connected to the ETHM-1 Plus module (the module is identified as “ETHM+GSM”). For
description of the settings, refer to the INT-GSM module manual.
6.1.3 IP filter
The module connected to the INTEGRA / INTEGRA Plus control panel with firmware version
1.15 (or newer) offers IP filter. Using IP filtering allows you to enhance security level of the
alarm system. Establishing connection with the Ethernet module (alarm control panel) will
only be possible from defined IP addresses or subnets. IP filtering does not apply to
communication via the SATEL server.
You can configure IP filtering for the incoming connections:
 from DLOADX program,
 from GUARDX program (applies also to web browser, mobile application and INTEGRUM
system),
 as part of integration.
In each case you can define the filtering rules in one of the following configurations:
 up to 4 allowed IP addresses,
 1 allowed subnet and up to 2 allowed IP addresses,
 up to 2 allowed subnets.
To activate the filtering feature, enter a value in one of the four fields available for the
given type of incoming connections.
IP Address – if the SUBNET option is disabled: the network address from which connection
with the Ethernet module can be established. If the SUBNET option is enabled: the IP
address used for defining the subnet from which connection with the Ethernet module can
be established.
subnet – if the option is enabled, you can define the subnet from which incoming
connections will be received by the module.
Subnet mask – mask used for separating the portion defining subnet from the IP address.
