2.3.1. Boom Housing
The boom part of the housing accommodates all the inside electronics, I/O ports, baery
compartments, SIM/Memory card slots. This secon gives informaon about the boom part with its
components.
In two sides, there are two covers with waterght locking mechanism to host two hot swappable
baeries as well as SIM and Memory cards.
Three connectors for communicaon and UHF radio are also available in the boom part in the above
gure. Please refer to communicaon secon for detailed informaon.
IF YOU ARE NOT USING THE 5-PIN PORT, 8-PIN PORT OR RADIO ANTENNA PORT, PLEASE PUT THE
PLASTIC PROTECTIVE PLUGS ON TO PROTECT CONNECTORS FROM BEING DAMAGED.
COMMUNICATION MODULE
According to dierent requirements, SL600 receiver can be equipped with UHF radio opons with
dierent parameters. Consult your local dealer to dene the correct UHF Radio Modem Opons.
Figure 2.3 shows the components of boom part.
Speaker
SIM Card Slot
Baery Compartments
MicroSD Card Slot
UHF Antenna
8- PIN prot and protecon plug
5- PIN port and protecon plug
