2. Receiver Physical Appearance
Power LED Yellow
Power LED Red
Power LED Red
Status LED Green
Status LED Green
Status LED Green
Status LED Orange
Satellite LED Green
Satellite LED Green
On
On
Flashing
O
On
Flashing
Flashing
On
Flashing
Power level = Good
Power level = Medium
Power Level = Low
In external data link, UHF mode, and
stac mode
Ntrip/Server connecon successful
Internet connecon is successful
1. geng correcon stream
2. collecon stac data in stac
mode
Tracking enough number of satellites
and posion has been calculated
Not enough number of satellites
being tracked to calculate posion
2.4. Communicaon
2.4.1. Communicaon Ports
Satlab SL600 is equipped with Bluetooth and two sealed ports called COM1 and COM2 for external
power supply and communicaons with external computer terminals.
Figure 2.x Communicaon ports
Table 2.3 LED Indicators
LED Status
Meaning
