The buons in the front panel are assigned to perform predened tasks by the rmware. These tasks
are listed and explained here. Should you have a task which is not explained in the guide, you probably
have applicaon specic task which would be explained in an applicaon note. Please for more
informaon, get in contact with your local dealer.
Operaon Mode:
Satlab SL600 receiver can be set to Stac mode to record raw data, RTK base staon to stream
correcons to a UHF Radio or an internet RTK Server, or RTK Rover staon by UHF or Internet.
In order to change the mode, double click on F1 so Voice help responds the acve mode among Base,
Rover or Stac. Please use push F1 once again to change. Finally press Power buon to conrm the
change. Conrmaon needs to be done in 10 seconds or it returns back to previous seng.
Telemetry Mode:
In order to deliver correcons from/to Satlab SL600 in corresponding Operaon Mode of Base or
Rover, there are three opons, namely External, GSM and UHF.
In external mode, for delivery of correcons, COM2 serial port @ 19200 bps rate is used. For cable
opons of COM2, please consult to your local dealer.
GSM opon is used for correcons over internet by using internal modem in the receiver in either base
or rover mode.
UHF opon has the similar way as GSM opon but correcons over UHF radio if the device is equipped
with radio.
In order to change the mode, double click on F2 so Voice help responds the acve mode among
External, GSM or UHF. Please use push F2 once again to change. Finally press Power buon to conrm
the change. Conrmaon needs to be done in 10 seconds or it returns back to previous seng.
Reset:
In order to reset the receiver F1 and F2 buons can be used depending on the desired level of reset.
Pressing F1 for more than 6 seconds will acvate the opons of reseng GNSS board and Self Test.
Aer these opons are acvated, pressing F1 will start Self Test and F2 will reset the GNSS receiver.
In the same way, pressing F2 for more than 6 seconds will acvate the opon of geng back to the
original sengs. Aer opon is acvated, pressing F2 will perform the operaon of Geng Back to the
Original Sengs.
2. Receiver Physical Appearance
