6 Installation of Options
105
CL4NX/CL6NX Service Manual
Note
When using the wireless LAN, adjust the antenna $
facing upward.
When transporting the printer, make sure that the
antenna
$ is facing downward.
5 Paste the WIFI/CCX Sticker 4 on the
front left bottom corner of the printer as
shown.
3
3
6
10mm
10mm
To Next Page
