SATO CL4NX Service Manual

Table of Contents
3
CL4NX/CL6NX Service Manual
5.15 Replacing the Torque Limiter for Liner Rewinder (Optional)...................... 92
5.16 Replacing the Timing Belt for Liner Rewinder (Optional) ........................... 93
6 Installation of Options........................................................................ 97
6.1 Installation of the Optional RTC (Real Time Clock) Kit.................................. 98
6.2 Installation of the Optional Wireless LAN Kit............................................... 100
6.2.1 Installation of the Optional Wireless LAN onto the Interface Combo Board .......... 100
6.2.2 Installation of the Optional Wireless LAN Interface Board..................................... 104
6.3 Installation of the Optional Cutter ................................................................. 106
6.4 Installation of the Optional Dispenser .......................................................... 111
6.5 Installation of the Optional Linerless Kit (CL4NX Only) .............................. 129
6.6 Installation of the Optional RFID Kit (CL4NX Only)...................................... 138
6.6.1 Installation of the Optional UHF RFID Kit .............................................................. 138
6.6.2 Installation of the Optional HF RFID Kit................................................................. 149

SATO CL4NX Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Maximum roll diameter	220 mm
Maximum printing width	104 mm
Printing media thickness	0.06 - 0.26 µm
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	271 mm
Height	321 mm
Weight	15000 g
