SATO CT400 - Page 160

FWaabbVccc
Hdddd
Box. Prints a box. For values aa, bbbb, cc, and dddd, see instructions
for horizontal and vertical lines. Units of measurement are dots.
Page 4-48
CT400 CT410
aa = Width of Horizontal Side 01 to 99
bb = Width of Vertical Side 01 to 99
cccc = Length of Vertical Side 0001-1424 0001-2136
dddd = Length of Horizontal Side 0001-0832 0001-1248
FWccVddd Vertical Line. Prints a vertical line. Units of measurement are dots. Page 4-48
CT400 CT410
cc = Width of Vertical Line 01 to 99
dddd = Length of Vertical Line 0001-3200 0001-4800
FXaaabccc
dddeee
Data Matrix. Sequential Numbering. Prints sequential numbered Data
Matrix 2-D symbols.
aaa = Number of duplicate labels (001-999)
b = Increment or decrement
+ Increment
- Decrement
ccc = Increment/decrement steps (001-999)
ddd = Sequential numbering start position (001-999). Referenced
to left side.
eee = Incremented data length (001-999). Measured from start
position.
Page 4-75
Gabbbccc(data) Custom Graphics. Allows the creation and printing of graphic images
using a dot-addressable matrix.
a = Specifies format of data stream to follow
B Binary
H Hexadecimal
bbb = Number of horizontal 8 x 8 blocks (001-152)
ccc = Number of vertical 8 x 8 blocks
(001-178 or 001-356 for 14" label)
data = Data to describe the graphic image
Page 4-44
Haaaa Horizontal Position. Specifies a field’s horizontal location across the
width of the label from the current base reference point. The units of
measurement are dots.
Page 4-58
CT400 CT410
aaaa = New Horizontal Position 0001-0832 0001-1248
IDaa Store Job ID. Stores the Job ID number.
aa = Job ID number assigned (01-99)
Page 4-46
INSTRUCTION DESCRIPTION PAGE
Appendix A: Command Quick Reference
SATOCT SeriesPrinters9001069A Page A-5
