SATO CT400 - Maxicode

Maxicode
Command Structure <ESC>BVa,b,c,ddddddddd,eee,fff,gggg.....<ESC>
a = Position of Maxicode symbol within the set, when used
in a structured append format 1~8.
b = Total number of Maxicode symbols in the set, when used
in a structured format 1~8.
c = 2 For Mode 2 Structured Carrier Message
for Domestic U.S. UPS shipments
3 For Mode 3 Structured Carrier Message
for International UPS shipments
4 Standard symbol
5 Not currently supported
6 Reader programming
ddd..ddd 9 digit numeric Postal Code
eee = 3 digit numeric Country Code
fff = 3 digit numeric Service Class
gg..g = Data, terminated by <ESC>
Character Set
MODE POSTAL CODE COUNTRY CODE SERVICE CTASS MESSAGE
LENGTH
2 9 digits max
numeric only
3 digits max
numeric only
3 digits max
numeric only
84 characters
alphanumeric
3 6 digits fixed
alphanumeric
3 digits max
numeric only
3 digits max
numeric only
84 characters
alphanumeric
4
6
“000000“
fixed data
“000“
fixed data
“000“
fixed data
91 characters
alphanumeric
Notes See AIM I.S.S specification for information on the structure of this
symbology.
Example <ESC>A<ESC>V0100<ESC>H0100
<ESC>BV1,1,2,123456789,840,001,[)<RS>01<GS>961Z01547089
<GS>UPSN<GS>056872<GS>349<GS>99999999<GS>001/005
<GS>029<GS>N<GS><GS>LENEXA<GS>KS<RS><EOT>
<ESC>Q001<ESC>Z
Appendix B: Bar Code Specifications
PageB-209001069A SATOCtSeriesPrinters
